MAXIMUM TEMPERATURE:
-20°C – 110°C
FINISH AVAILABLE
Plain, Electro-Galvanized, Hot Dip Galvanized, Zinc Flake & Epoxy Coated.
APPLICATION
HEAVY DUTY PIPE HANGER WITH LINING is recommended for non-insulated stationary heavy pipelines in either a horizontal or vertical position. It can be used for supporting pipes along with roof as well as along wall. It is used where loads to be carried are larger in magnitude.
MATERIAL
Mild Steel. Also, other materials can be provided on request.
CONSTRUCTION
HEAVY DUTY PIPE HANGER WITH LINING consists of piece of mild steel shaped to wrap around the pipe. Quick-locking permits simple and fast installation. Large opening angles for easy insertion of the pipes. Clamping range without gaps. Reduces noise up to 18 dB.
